XLN Bikes (MSX) by PlattySoft

# XLN Bikes

XLN Bikes is a single player game inspired by the classic Tron Lightcycles.

Player moves in a restricted grid using cursors. AI will try to take them on.

# How to see the code

Press CTRL+STOP and the game will stop, then you can LIST.

If you insert the disk after the emulator has booted, you can do: LOAD "autoexec.bas", and then LIST

# Design decisions

The MSX only allows for 2 colors in each line of 8x1 pixels. This limitation makes it so if 2 bikes are too close, the colors clash (know as color spill)

Given color clash, I had the choice:

* Free grid, allow color clash, which felt really distracting

* Free grid, both players use the same color, which looked boring

* Restric the grid to 8 pixels, which is what I did

With a restricted grid, I felt like it needed guiding lines, which took almost 2 entire lines to draw

With the remaining lines of code I had to choose what to prioritize:

* AI player

* Sound effects

* Random start position

* Crash animations

There was only enough space for 2 of those, so I decided the random start was giving the game a bit more fun into making games different.

2 Players was fun, but a bit too obvious, so I went for an AI to be able to play onmy own

While making the game, I had to decide on the control scheme for the player:

* Cursor direction

* Turn left or right

If using cursor direction, you need to prevent U-Turns, with turning, we need to implement debouncing.

I tried both control schemes and cursor direction felt a lot more intuitive, preventing U-Turns and converting the stick direction into speed on both axis is some of the weirdest code in the example.

# Code explanation

## Variables

For obvious reasons they are 1 letter long, so not as descriptive as they should)

* X, Y: Position of Player (X,Y)

* V, W: Speed of Player in X and Y axis

* C, D: Position of AI (X,Y)

* A, B: Speed of AI in X and Y axis

* T: Time interval, we allow turning each 8 steps, to make sure we are in the grid

* Z: Current direction of the player (in the same format as read from STICK)

* S: Stick reading

* R: The AI player is trying to tuRn. Used to verify it does not turn into a wall

## Line desciption

1-2 - One-off initialization of color, screen, open "GRP:" screen for printing text and defining funcions to randomize the starting position of the players and check for collisions, also constants for strings

3:   Draw "XLN-Bikes" and "PUSH SPACE KEY", initialize most variables for the game

4-5: Check for push space key, upon pressing, initialize the random generator, clear the screen and draw the grid

6:   Main loop, update X,Y values and draw a new point, after 8 times it moves on for checking turns

7-8: When in an intersection, we can turn. AI will turn if it sees a wall or "at random", when turning it tries to get towards the players, if the turn leads to a wall, it will turn the other way

9:   Check the stick and set the speeds on X and Y based on that

10:  Check for collisions and if so, display a game over screen and get back to line 3, otherwise, back to line 6

## Explanation of some weird code

We want to check that we do no go backwards (instant U-Turns will result in death)

The stick positions are 1 (up), 3 (right), 5 (down), and 7 (left) (2, 4, 6, and 8) are diagonals, which are ignored.

This is done with the code:

S=STICK(0)

IFSMOD2=1ANDS+Z<>6ANDS+Z<>10THENZ=S

First we only look at odd numbers of S (S Mod 2=1), then we know that the current direction (Z) + new direction (S) can not be 6 or 10.

We assign speed on X and Y (V and W), this is based on the current direction, it is a lot shorter than checking for each position and assigning it, unfortunately, it ia a lot less obvious, but it does follow this table:

* Z=1 -> V=0,  W=-1

* Z=3 -> V=1,  W=0

* Z=5 -> V=0,  W=1

* Z=7 -> V=-1, W=0

Which can be compressed to just this code:

V=SGN(5-Z)ANDZ<>1

W=SGN(Z-3)ANDZ<>7
